Q: What does A-Level Physics: 20) Nuclear Physics Guide cover? A: From Rutherford 's gold-foil to binding-energy curves, this post unpacks Topic 20 of the 2026 H2 Physics syllabus for IP students and parents.
TL;DR The nucleus is tiny yet mighty: its femtometre scale explains why most alpha particles sail straight through foil (>99.9%path) while its binding-energy curve bankrolls both fission reactors and the Sun. Master the decay law, half-life algebra and conservation check-list to secure >12 marks of Paper 1 MCQs and every WA radioactivity question.
1 The nuclear atom
Rutherford 's alpha-scattering revealed a dense, positively-charged core less than 10−14m across - about 1fm
- because only a few
α
particles were deflected through large angles.
2 Nuclear bookkeeping: Z, A and isotopes
Symbol
Meaning
Typical size
\(Z\)
Proton (atomic) number
\(1 \rightarrow 118\)
\(A\)
Nucleon (mass) number
\(1 \rightarrow 300\)
Write nuclides as XZAX2Z2AX. Example: X614X26214C has 6 protons and 8 neutrons.
Isotopes share the same Z but different A; their chemical behaviour is identical, yet nuclear stability varies.
3 Radioactive decay fundamentals
3.1 Randomness & background
Each nucleus decays spontaneously; count-rate fluctuations seen on a GM tube histogram are statistical proof. Natural background comes from cosmic rays, terrestrial isotopes and internal potassium-40.
3.2 α, β, γ radiations
Radiation
Composition
Charge
Ionising
Penetration
\(\alpha\)
Helium nucleus \(^4_2 \text{He}\)
+2
Very strong
Paper
\(\beta^-\)
Electron \(e^-\)
-1
Moderate
\(~5 \space \text{mm} \space \text{Al}\)
\(\gamma\)
Photon
0
Weak
cm-thick Pb
Penetration inversely tracks ionising power.
4 Measuring decay
Define activityA (in Bq) as decays per second; A=λN. The decay law
N=N0e−λt
gives an exponential curve. Half-life is
t1/2=λln2.
⮕ Mini-drill: show that after 3 half-lives, N=N0/8.
5 Conservation laws & the (anti)neutrino
Nuclear equations conserve nucleon number, charge and mass-energy. Example:
714N+24He→817O+11H
In β− decay, missing energy and momentum led Pauli to postulate an elusive neutral particle - the neutrino - restoring conservation.
6 Mass defect & E=mc2
A nucleus weighs less than its separated nucleons; the deficit Δm converts to binding energy
Eb=Δmc2.
This is Einstein 's mass-energy equivalence. For 4He, Eb≈28MeV.
7 Binding-energy curve: fusion vs fission
Plotting binding energy per nucleon against A peaks near iron-56 (8.8MeV).
Fusion of light nuclei (e.g. D-T) moves uphill, releasing energy - the Sun and recent stellarator records rely on this.
Fission of A>235 splits heavy nuclei into medium ones, also moving toward the peak.
8 Applications & hazards
Sector
Isotope
Half-life
Radiation
Why chosen
PET imaging
\(^{18} \text{F}\)
110 min
\(\beta^+\)
Short \(t_{1/2}\), emits annihilation \(\gamma\) pairs.
Thickness gauge
\(^{90} \text{Sr}\)
29 y
\(\beta^-\)
Medium penetration, long life.
Smoke detector
\(^{241} \text{Am}\)
432 y
\(\alpha\)
Strong ioniser, low penetration.
Hazards: ionising radiation can damage DNA; shielding, distance and time minimise dose.
9 WA timing hacks
Draw a decay curve sketch before diving into algebra.
Label nuclei with Z and A first to avoid conservation slips.
Use ln key for half-life Qs: λ=0.693/t1/2.
Comprehensive revision pack
9478 Section VI, Topic 20 Syllabus outcomes at a glance
Outcome (a) - describe nuclear structure, isotopes and decay types.
Outcome (c) - use decay equations to conserve nucleon number, charge and energy.
Outcome (d) - interpret binding energy, mass defect and fission/fusion energetics.
Outcome (e) - evaluate nuclear applications and safety considerations.
Concept map (in words)
Start with nuclear notation (A, Z). Link decay types (alpha, beta, gamma) with changes in A and Z. Use activity A=λN and N=N0e−λt for quantitative predictions. Binding energy per nucleon explains energy release in fission and fusion. Conservation checks keep equations balanced.
Key relations
Quantity / relation
Expression / reminder
Activity
\(A = \lambda N\)
Decay law
\(N = N_0 e^{-\lambda t}\)
Half-life
\(t_{1/2} = \ln 2 / \lambda\)
Mass defect
\(\delta m = Zm_p + (A-Z)m_n - m_\text{nucleus}\)
Binding energy
\(E_b = \delta m \space c^2\)
Energy released per fission
\(\delta E = \left( \text{mass}_\text{initial} - \text{mass}_\text{final} \right) c^2\)
Dose reduction principles
Shielding, distance, time (ALARA)
Derivations & reasoning to master
Exponential decay: derive activity dependence from differential equation dtdN=−λN.
Half-life relation: show t1/2=ln2/λ by solving N=N0/2.
Binding energy per nucleon curve: explain why fusion of light nuclei and fission of heavy nuclei release energy.
Mass-energy conversions: practise converting atomic mass units to MeV using 1u=931.5MeV.
Worked example 1 - decay counting
A sample contains 1.2×1018 nuclei of an isotope with half-life 8.0 days. Calculate (a) decay constant, (b) initial activity, (c) activity after 24 days.
Approach: λ=ln2/t1/2; A0=λN0; A=A0e−λt.
Worked example 2 - binding energy release
Using mass data for U-235 fission into Ba-141 and Kr-92 plus three neutrons, compute energy released per fission in MeV. Convert to joules and compare with chemical energy scales.
Method: determine mass defect, multiply by c2, convert units; emphasise orders of magnitude.
Practical & data tasks
Plot ln N vs t for simulated decay data to extract lambda from gradient.
Calculate shielding thickness needed for different radiation types using attenuation coefficients.
Analyse CANDU reactor fuel cycle or medical tracer half-life scheduling as case studies.
Common misconceptions & exam traps
Forgetting to convert half-life units (minutes vs seconds).
Mixing mass units (u vs kg) when calculating binding energy.
Ignoring neutrinos in beta decay when balancing energy/momentum.
Assuming gamma decay changes nucleon numbers (it does not).
Quick self-check quiz
Define activity. - Rate of decay of nuclei (decays per second).
How many half-lives reduce activity to 1/32? - Five.
Why is fusion of light nuclei energetically favourable? - Binding energy per nucleon increases toward iron peak.
Name the particle emitted in beta-minus decay in addition to electron. - Antineutrino.
State one medical application of isotopes. - PET imaging with X18X2218F, radiotherapy with X60X2260Co, etc.
Revision workflow
Re-derive decay and half-life relations without notes weekly.
Practise binding energy calculations with mass tables to stay fluent in unit conversions.
Work through two past-paper questions involving decay chains and shielding.
Summarise pros/cons of nuclear power, medical usage, and waste management for essay-style prompts.
Practice Quiz
Test yourself on the key concepts from this guide.
Parents: book a 60-min Nuclear Physics clinic two weeks before WA 2 to tackle binding-energy graph sketching.
Students: print the table in §8, stick it on your desk, and quiz yourself while waiting for downloads to finish.
