Q: What does A-Level Physics: 7) Circular Motion Guide cover? A: From angular displacement to centripetal force, this guide unpacks Topic 7 of the 2026 H2 Physics syllabus for IP students and parents.
TL;DR Circular motion looks deceptively “plug-and-chug”, but it underpins vertical-circle forces, banked tracks, and conical pendulums - and it feeds directly into gravitation, satellites and SHM later. Nail radians, v=rω, a=rω2 and F=rmv2
early to free up mental bandwidth for the harder integrations later in the IP track.
Concrete example: how to use this page
For a car turning a corner, do not invent an outward force. Draw the real force that points inward, then set it equal to mv2/r. The same habit works for strings, tracks, and satellites.
Cross-reference our free H2 Physics notes for adjoining gravitation/SHM chapters and downloadable drills so your revision plan follows the full Topic 7→Topic 9 arc. For the full topic map and paper weightings, see our H2 Physics Syllabus 2026-27 overview.
1 Where this fits in the syllabus
The SEAB 2026 H2 Physics syllabus positions Circular Motion as Topic 7 in Section I - Mechanics. IP schools typically teach it right after Dynamics so that normal-reaction questions in vertical circles feel like natural extensions.
1.1 Why parents should care
Sign slips in the radial direction (and mixing up centripetal vs “centrifugal” language) are common sources of lost method marks early on; fixing them early makes later gravitation/satellite/SHM work much smoother.
2 Angular displacement in radians
Radians measure “arc length per radius”, making every calculus derivative in later topics cleaner.
Quick check: Half a revolution = π rad (=180∘).
WA tip: Always label the axis on your graph in radians (not degrees) to avoid losing easy accuracy marks.
3 Angular velocity ω
Define:
ω=ΔtΔθ
with θ in radians and ω in s−1. The linear (tangential) velocity at radius r is
v=rω.
This falls straight out of “distance = rate × time” when the arc length s=rθ is divided by t.
4 Centripetal acceleration ac
Uniform circular motion means the speed is constant but the velocity changes direction, producing an inward acceleration
ac=rω2=rv2.
Direction: Always toward the geometric centre, perpendicular to v.
Intuitive cue: Rotate the velocity vector by 90° then scale it by rv.
5 Centripetal force Fc
Newton's Second Law packages the previous result into
Fc=mac=mrω2=rmv2.
The sharper the bend (small r) or the faster the motion (large v), the larger the required inward force.
5.1 Radial force setup routine
Use this routine before substituting into F=rmv2. It keeps "centripetal force" as a resultant, not a new force to add to the diagram.
Step
What to do
Example check
1
Mark the centre of the circle
For a vertical loop, the centre is inside the loop
2
Draw the radial arrow toward the centre
At the top, inward is downward; at the bottom, inward is upward
3
List only real forces on the object
Weight, tension, normal reaction, friction, or thrust
4
Resolve forces along the radial direction
Forces pointing inward are positive in the radial equation
5
Set radial resultant equal to rmv2
Use the local speed at that point, not automatically the starting speed
Worked force map:
Position / scenario
Inward direction
Radial equation
Mass on a horizontal string
Toward the hand or centre
T=rmv2
Car at the top of a convex hill
Downward
mg−N=rmv2
Cart at the bottom of a loop
Upward
N−mg=rmv2
Conical pendulum
Horizontally inward
Tsinθ=rmv2, with Tcosθ=mg
Trap check: if your free-body diagram contains a separate arrow labelled "centripetal force", redraw it. The inward resultant is made from real forces already on the object.
5.2 Common exam archetypes
Scenario
Catch
Remedy
Car cresting a hill
Normal reaction can drop to zero
Equate weight to centripetal requirement
Roller coaster loop
Radial direction flips at the top
Draw FBD for each quadrant
Conical pendulum
Resolve tension into radial and vertical components
Use Tcosθ=mg then Tsinθ=rmv2
6 Mini-drill (3 min)
Express 720° in radians. Answer:4π rad.
Solve: A 0.40kg mass whirls at 5.0m⋅s−1 in a horizontal circle on a 0.60m string. Assume the tension provides the centripetal force. Find the tension. Answer:F=rmv2=0.600.40×5.02≈17N
Explain why passengers feel "heavier" at the bottom of a Ferris-wheel arc. Hint: Reaction = mg+rmv2.
7 Bridging to Paper 4 practical
To verify Fc=rmv2 experimentally, keep one variable fixed and plot a straight-line graph:
fixed r: plot Fc against v2 → gradient =m/r
fixed v: plot Fc against 1/r → gradient =mv2
Always quote ± one standard error from the LINEST output.
8 Three WA timing rules
Use syllabus pacing as a guide: Paper 2/3 average ~1.6 min/mark; Paper 4 ~3 min/mark.
Write the radial direction beside your FBD before summing forces.
Keep units visible; missing the “per-second-squared” costs one accuracy mark.
Need structured practice on Circular Motion? Our H2 Physics tuition programme covers this topic with weekly problem sets and Paper 4 practical drills.
Comprehensive revision pack
9478 Section II, Topic 7 Syllabus outcomes
Candidates should be able to:
(a) express angular displacement in radians.
(b) show an understanding of and use the concept of angular velocity.
(c) recall and use v=rω to solve problems.
(d) show an understanding of centripetal acceleration in the case of uniform motion in a circle, and qualitatively describe motion in a curved path (arc) as due to a resultant force that is both perpendicular to the motion and centripetal in direction.
(e) recall and use centripetal acceleration a=rω2, and a=rv2 to solve problems.
(f) recall and use F=mrω2, and F=rmv2
Concept map (in words)
Convert to radians, compute angular quantities, then translate back to linear variables when forces are required. Always identify the radial direction because the net inward force equals rmv2. Vertical situations demand additional energy/force checks at top and bottom. Banked motion and conical pendula link circular motion to equilibrium concepts from Topic 2.
Key relations
Quantity
Expression
Angular velocity
ω=ΔtΔθ
Angular acceleration
α=ΔtΔω
Linear-angular link
v=rω,at=rα
Centripetal acceleration
ac=rω2=rv2
Centripetal force
Fc=mac=mrω2=rmv2
Banking condition
tanθ=rgv2
Rotating frame weight
Apparent weight=mg±rmv2
Derivations & reasoning to master
Centripetal acceleration: derive ac=rv2 using vector subtraction or calculus (limit of chord angles).
Banked-track formula: resolve normal reaction components and solve for frictionless optimum.
Vertical circle tension: write Newton's 2nd law at top and bottom, showing how minimum speed arises from T≥0.
Energy + force blend: use energy conservation to find speed at various points, then plug into rmv2 for required force.
Vertical-loop contact checkpoint
For vertical-circle questions, decide first whether the object is held by a string, pressed by a track, or just maintaining contact with a surface. The radial equation changes because the real inward forces change at each position.
Position or clue
Inward direction
Setup move
Common trap
Top of an inside loop
Downward
Weight and normal reaction both point inward: mg+N=rmv2.
Subtracting weight just because the object is above the centre.
Bottom of an inside loop
Upward
Normal reaction points inward while weight points outward: N−mg=rmv2.
Reusing the top equation with the same signs.
Just maintaining contact at the top
Downward
Set N=0, so mg=rmv2
String just taut at the top
Downward
Set T=0 for the limiting case.
Forcing a positive tension even at the minimum speed.
Worked check: if a cart just maintains contact at the top of a loop of radius 1.8m, then
mg=rmv2⇒v=gr=9.81×1.8≈4.2m⋅s−1.
Misconception check: the normal reaction becomes zero at the limiting top speed, but weight is still acting and still supplies the required inward resultant.
Worked example 1 - vertical loop
A 0.50kg cart enters a vertical loop of radius 1.8m at 12m⋅s−1 at the bottom. Find (a) its speed at the top (neglect friction), (b) the normal reaction at the top and bottom.
Sketch solution: use energy to determine the speed at the top v2=u2−4gR. Substitute into rmv2 to calculate reactions: top uses N+mg=rmv2, bottom uses N−mg=rmv2.
A 0.25kg bob moves in a horizontal circle of radius 0.65m with period 1.7s. Determine the string tension and the angle it makes with the vertical.
Approach: compute angular speed ω=T2π, then v=rω. Apply the radial equation Tsinθ=rmv2 and vertical equilibrium Tcosθ=mg to solve simultaneously.
ω=1.72π≈3.70s−1,v=0.65ω≈2.40m⋅s−1.
tanθ=rgv2≈0.904⇒θ≈42∘,T=cosθmg≈3.31N.
Practical & data tasks
Perform a whirling bung experiment; plot v2 vs radius and extract g from the gradient.
Use accelerometer data on a rotating turntable to compare measured radial acceleration with rv2.
Model banked curves using a coin on a wedge; measure limiting speed before slipping.
Common misconceptions & exam traps
Treating “centripetal force” as a new force; it is just the resultant toward the centre.
Using mg=rmv2 blindly without checking position in the vertical circle.
Mixing tangential and radial components when acceleration is not uniform.
Forgetting to convert revolutions per minute to radians per second.
Quick self-check quiz
Express 3 revolutions per second in rad⋅s−1. - 6πrad⋅s−1.
What provides the centripetal force for a satellite in circular orbit? - Gravitational attraction.
At the top of a vertical loop, what is the minimum speed to keep contact? - v=gr.
For a car on a banked track with frictionless surface, what relation links banking angle to speed? - tanθ=rgv2.
Why do occupants feel lighter at the top of a ferris wheel? - Normal reaction decreases because some of the centripetal requirement is supplied by weight.
Revision workflow
Redo three past-paper problems covering vertical circles, conical pendula and banked tracks.
Re-derive ac=rv2 weekly to keep the concept fresh.
Create a table comparing radial forces in different contexts (tension, weight, normal, electrostatic).
Practise sketching velocity and acceleration vectors for points around a circle without referencing notes.
Practice Quiz
Test yourself on the key concepts from this guide.
Parents: Book a 60-min Circular Motion clinic before WA 2 to bullet-proof free-body diagrams.
Students: Paste ac=rv2 on your water-bottle and test it on tomorrow's vertical-circle worksheet.
