Measuring Planck's Constant with LED Thresholds for H2 Physics Practicals
30 Nov 2025, 00:00 Z
Want small-group support? Browse our A-Level Physics Tuition hub. Not sure which level to start with? Visit Physics Tuition Singapore.
Looking for the full lab practical series? Visit the H2 Physics Practicals.
Practical course certificate note
For practical, lab, and experiment courses, Eclat Institute may issue an internal Certificate of Completion/Attendance based on participation and internal assessment.
- This is an internal centre-issued certificate, not an MOE/SEAB qualification or accreditation.
- Recognition (if any) is determined by the receiving school, institution, or employer.
- For SEAB private candidates taking science practical papers, SEAB states you should either have taken the subject before or complete a practical course before the practical exam date.
View our sample certificate template (Current sample layout (design may be refined over time))
Planning a revision session? Use our study places near me map to find libraries, community study rooms, and late-night spots.
Q: What does Measuring Planck's Constant with LED Thresholds for H2 Physics Practicals cover?
A: Build a repeatable LED threshold experiment that nails Planck's constant within exam tolerances, reinforces quantum concepts.
TL;DR
Use a string of different coloured LEDs, a variable power supply, and spreadsheet regression to plot photon energy against frequency.
The intercept of the best-fit line givesh/e; when multiplied by the electronic charge it often lands close to the accepted Planck constant if uncertainties and controls are handled carefully.
Bake in calibration checks, dark-room controls, and full uncertainty paragraphs to turn a simple demo into a top-tier Paper 4 investigation.
Why This Experiment Hits the 9478 Syllabus
H2 Physics candidates must demonstrate mastery of quantum photoelectric ideas and linear data analysis. The LED threshold experiment ticks both boxes:
- Threshold voltage maps directly onto photon energy
E = hf, making the link between circuit measurements and quantum theory explicit. - The procedure mirrors SEAB Paper 4 expectations - control temperature, justify graphical methods, and estimate uncertainties on slope and intercept.
- Students rehearse digital acquisition workflows that align with Paper 4’s emphasis on spreadsheet analysis.
Apparatus Checklist
| Item | Notes |
| Assorted LEDs (violet to red) | Use at least five distinct peak wavelengths between 400–650 nm. |
| Variable DC supply (0–6 V) or USB-C PD trigger | Fine voltage control in 0.01 V steps lets you land exactly on the threshold. |
| Series resistor (1 kΩ) & breadboard | Limits current spikes that can damage LEDs. |
| Digital multimeter or Arduino DAQ | Log both voltage and current; ensure millivolt resolution. |
